Digital blood pressure monitor with wristband
This fully automatic electronic sphygmomanometer is designed for use by medical professionals and for home use. This is a non-invasive system for measuring the systolic and diastolic arterial pressure, plus cardiac frequency by using an inflatable cuff around the upper portion of the wrist.
Based on oscillometric methodology and integrated pressure sensor, can measure blood pressure and pulse rate automatically and noninvasively.
The LCD displays blood pressure and pulse rate. The last 60 measurements can be stored in memory with date and time.
Characteristics:
- Oscillometric method
- Cuff size: 14-19.5 cm / 5.5-7.6 in
- Memory of 60 recent records
- Arrhythmia detection
- Power: 2 AAA batteries 1.5 V
Contents and display indicators:
- Memory Button
- Start Button
- LCD screen
- Indicator blood pressure level
- Memory indicator
- Low battery indicator
- Date / Time
- Systolic pressure
- Indicator blood pressure level
- Diastolic pressure / pulse frequency (alternating)
- Irregular heartbeat symbol
- Indicator "ready for inflation”
Technical specifications:
1. Product Name: Blood Pressure Monitor.
2. Model: KD-735.
3. Classification: Internal supply, Type BF applied part, IPX0, not AP or APG, continuous operation.
4. Device Size: Approx. 85mm × 28mm × 64.5 mm (3 11/32 "x 2 17/32" x 1 3/32 ").
5. Contour Sleeve: 14cm - 19.5 cm (5 1/2 "- 7 11/16").
6. Weight: Approx. 110 g (3 7/8 oz.) (Excluding batteries).
7. Measurement Method: Oscillometric method, automatic inflation and measurement.
8. Memory: 60 measurements with time stamp and time.
9. Power supply: batteries 2 x 1.5 V AAA size.
10. Measuring range:
- Cuff pressure: 0-300 mmHg.
- Systolic: 60-260 mmHg
- Diastolic: 40-199mmHg
- Pulse Rate: 40-180 beats / minute
11. Accuracy:
- Pressure: ± 3 mmHg
- Pulse rate: ± 5%
12. Ambient operating temperature: 5 º C-40 º C (41 º F-104 º F).
13. Operating Humidity: ≤ 90% RH.
14. Ambient temperature Storage and transport: -20 º C-55 º C (-4 º F-131 º F).
15. Humidity storage and transportation: ≤ 95% RH.
16. Ambient pressure: 80KPa-105KPaa.
17. Battery life: Approximately 270 measurements.
18. List of all components of the pressure measurement system, including accessories: pump, valve, LCD, sleeve, Sensor.
Note: Product specifications are subject to change without notice.
Accessories included:
- 1 arm cuff.
- User's manual.
*You can find in our webpague the following references as optional accessories:
647-PCA9001
647-PCA7101
647-ACH9020
647-PCL2805
Accessories included:
- 1 arm cuff
- Instruction manual
